Surgical excision of subfoveal nodules and histopathological findings in pediatric patients with Coats’ disease
关键词
摘要
全文
HIGHLIGHTS
INTRODUCTION
Coats’ disease is a sporadic, chronic retinal vascular condition characterized by telangiectatic and aneurysmal retinal vessels with intraretinal and subretinal lipid exudation and fluid. Georges Coats first described it in 1908 as a unilateral condition characterized by exudative retinal detachment and telangiectasia in a young man.[1] The symptoms of patients with Coats’ disease were decreased vision, strabismus, leukocoria and amblyogenic refractive error.[2-4] Lipid exudation and massive accumulation in or under the retina are the main causes of vision loss. Long-term accumulation of large amounts of lipids may lead to migration to the macula fovea, where they form subfoveal nodules. These nodules can progress to fibrous nodules over time, which are difficult to subside. Daruih et al. reported that 52.5% of Coats’ disease patients with stage 2B or 3A1 presented with a subfoveal nodule, which was associated with a worse visual outcome.[5]The treatment modalities for Coats’ disease include ablative therapy with laser and cryotherapy, intravitreal anti-vascular endothelial growth factor (VEGF) therapy, and surgical options, including external subretinal drainage with or without scleral buckling and vitrectomy.[6] Many ophthalmologists have explored other approaches to treat the specific complications caused by Coats disease, includingsurgical drainage of large macular cystoid spaces,[7] perfluoro-octane-assisted external drainage of severe exudative retinal detachment.[8] But there are no good solutions reported for the massive subfoveal exudates and fibrosis, while thick foveal exudates and fibrosis usually predict a worse functional outcome. Surgical excision of subfoveal membranes and collaborative submacular surgery have been described for subfoveal neovascularization in children secondary to choroidal neovascularization.[9] The removal of subfoveal nodules and exudation has not been reported in children secondary to Coats’ disease. The purpose of the present study was to investigate the surgical outcome of excision of subfoveal nodules in pediatric patients with Coats’ disease and to report the histopathological findings of subfoveal nodules from these patients.
METHODS
We retrospectively reviewed a consecutive series of 6 pediatric patients with stage 3A or 3B Coats’ disease with subfoveal nodules in the macula who underwent submacular surgery. General ophthalmic examination, including best-corrected visual acuity (BCVA), slit lamp examination, and intraocular pressure (IOP), were performed preoperatively and postoperatively in all the patients. Young children who are unable to cooperate with visual acuity assessment was recorded not applicabele (N/A), and those who are unable to cooperate with non-contact tonometry was assessed with finger method for intraocular pressure assessment. Fundus photography and fluorescein and angiography were performed using a RetCam II (Clarity Medical Systems, Pleasan-ton, CA, USA). The study was approved by the Institutional Review Board of West China Hospital and was performed in accordance with the Declaration of Helsinki. Written informed consent was obtained from the guardians of those patients.A subfoveal nodule was defined on fundus examination as a yellow, exudative, protruding, spheroidal lesion. The nodule size was estimated as the papillary diameter. The lesion was confirmed by fundoscopy, fundus fluorescein angiography (FFA) and optical coherence tomography (OCT). On fundoscopy, the presence of an associated vascular component and the presence of macular exudation were also noted. Findings from fluorescein angiography on a RetCam II were recorded. Spectral-domain OCT (SD-OCT; Cirrus, Zeiss, CA) data were also recorded when available.
One experienced vitreoretinal surgeon (F.L.) performed all the surgeries. First, pars plana vitrectomy was performed after posterior vitreous detachment, and then the internal limiting membrane was removed. Second, a 27-gauge syringe needle was inserted into the subretina, and a balanced salt solution was injected to form a small bubble to elevate the neuroretina. Retinal scissors were used to perform a retinotomy, and retinal forceps were inserted beneath the neuroretina to grasp the nodule and remove it gently. The exudate was washed away by the balanced salt solution. After that, perfluorocarbons were used to flatten the retina, and fluid-air exchange was performed prior to laser photocoagulation of the retinal incision. Photocoagulation to the telangiectasias was usually selected. Cryotherapy was employed when the retinal detachment was shallow enough to allow approximation of the cryoprobe to the telangiectasias using the scleral technique. Finally, silicon oil was injected into the vitreous. The patient was instructed to keep a face-down position after surgery for 1 month. Silicon oil was removed 3 months later, and all the patients were followed up for at least 6 months.
All of the 6 eyes underwent nodule removal, pathological procedures were performed at our institution, and the nodules were available for the histopathological analysis.
RESULTS
The six patients were aged between 1 and 8 years, and four of the six patients were male. The course of disease ranged from 6 months to 24 months. Three patients in this series had unilateral 3A1, two had 3A2, and one had 3B Coats’ disease with total exudative retinal detachments. Three patients had previously received anti-VEGF therapy and laser therapy. Five patients had the right eye involved. On presentation, vision in the affected eye ranged from 0.08 to light perception. All of the six patients had foveal nodules. The average age of patients at the time of surgery was 5.17±2.40 years old. After surgical removal of the subfoveal nodules, the patients had an average follow-up of 9.2±1.5 months (range, 7-11 months), and postoperative visual acuity ranged from light perception to 0.15. For older children (patient #1,2,3) who can cooperate with non-invasive intraocular pressure measurement, we performed intraocular pressure testing, which were 13.1 mmHg, 9.5 mmHg and 17.3 mmHg; For young children (Patient 4,5,6) who are unable to cooperate with non-invasive intraocular pressure measurement, we performed finger intraocular pressure measurement, which were Tn for these patient.These clinical findings are summarized in Table 1.
Table 1 Clinical characteristics of six patients with Coats’ disease
|
Case |
Gender |
Age(y) |
Course of disease(m) |
Pretreatment |
Eye |
Stage |
Number of quadrants with telangiectasia |
Size(mm)
|
Baseline VA
|
Post-surgery VA
|
Follow up(m) |
|
1 |
M |
8 |
14 |
Native |
OD |
3A1 |
2 |
3*2 |
CF |
LP |
10 |
|
2 |
M |
5 |
12 |
Anti VEGF,laser |
OD |
3A1 |
4 |
4*2 |
CF |
CF |
9 |
|
3 |
F |
8 |
13 |
Anti VEGF,laser |
OS |
3A2 |
3 |
3*4 |
0.08 |
0.1 |
10 |
|
4 |
M |
2 |
15 |
Subretinal fluid drainage, Anti VEGF, laser |
OD |
3B |
4 |
2*3 |
NA |
NA |
11 |
|
5 |
F |
4 |
24 |
Native |
OD |
3A2 |
3 |
1*1 |
HM |
0.15 |
8 |
|
6 |
M |
4 |
6 |
Native |
OD |
3A1 |
4 |
3*2 |
CF |
0.04 |
7 |
OD: right eye, OS: left eye, VEGF: Vascular endothelial growth factor, VA: visual acuity, CF: counting figures, HM: hand movement, LP: light perception.
DISCUSSION
Subfoveal nodules are ominous results of exudate accumulation with fibrosis in the macula of patients with Coats disease with or without treatment. This is one of the causes of vision loss in patients with Coats’ disease. In our study, 6 patients with subfoveal nodules presented with stage 3A1, 3A2 or 3B disease and had low vision at presentation (from LP to 0.08). After surgical removal of subfoveal nodules, 4/6 of the patients had a visual acuity better than that before surgery, and there was no evidence of spontaneous regression of fibrosis. No increase in intraocular pressure, cataracts, retinal detachment, vitreous hemorrhage, or endophthalmitis was observed during the follow-up.Anti-VEGF therapy is a first-line treatment for choroidal neovascularization but has a limited effect on macular fibrosis. Surgical removal of choroidal neovascularization has been reported in children and adults, but there is no evidence of a significant improvement in visual acuity supports the concept that submacular surgery is safe in children with neovascular membranes.[9] Our study showed that surgical removal of submacular nodules was safe in children with Coats’ disease. Several factors may lead to favorable surgical outcomes in pediatric patients who undergo removal of subfoveal nodules compared with surgical outcomes in pediatric and adults patients with subfoveal membranes
associated with choroidal neovascularization. First, the subfoveal nodule in Coats’ disease is composed of mature fibrotic tissue with less vascularization, and isolating the nodule from other tissues was less likely to be associated with massive bleeding. Second, subfoveal nodules have a solitary ingrowth site in the subretina, unlike choroidal neovascularization, for example, in age-related macular degeneration, which has multiple ingrowth sites in the subRPE.[10] Therefore, we speculate that the characteristics and location of lesion tissue may have contributed to a favorable result to some extent. However, during our long-term follow-up, vision did not improve significantly, and the RPE and neuroretinal layers exhibited some atrophy. These findings suggest that early treatment and minimizing the chance of nodule occurrence are needed in the future.
Cholesterol granuloma, calcium and osseous metaplasia in subfoveal nodule were reported in enucleated children’s eyes with Coats’ disease in 1984.[11]Daruich reported subfoveal nodule from two eyes with Coats’ disease including fibrin admixed with spindle cells, macrophages and pigmented cells.[5] In our study, histopathologic analysis revealed that these nodules were fibrous tissue, which was composed mainly of fibroblasts and myofibroblasts, cholesterol clefts, lipid-laden macrophages, multinucleated giant cells, ossified tissue, pigments and foam cells. Fibroblasts and myofibroblasts are essential for wound healing, and myofibroblasts are activated fibroblasts that participate in tissue remodeling following insult.[12] When a large amount of lipids are deposited in the macular fovea, injury to macular tissue causes the recruitment and activation of inflammatory cells and fibroblasts, the proliferation of activated fibroblasts (myofibroblasts), and the deposition of extracellular matrix (collagens, fibronectin, laminin and glycosaminoglycans); additionally, the extracellular matrix spreads to cover the damaged tissue.[13] The exudates from telangiectasia contain many lipids and attract macrophages to lesions to swallow lipids. A group of macrophages, called lipid-laden macrophages, localize to lipid deposits and become lipid-laden cells, giving them a foamy appearance under the microscope. Some cholesterol clefts could also be observed in the tissue of subofveal nodules. Ossified tissue and hyalinization were first observed in the margins of nodules in patients with Coats’ disease, and fibrous tissue collagen was speculated to be the origin of the hyalinized material, which turned into ossified tissue. Pigmentation was observed in the nodule, possibly because of the destruction and phagocytosis of RPE cells during nodular growth. These pathological changes suggested that pharmaceutical approach may have a limited effect on subfoveal nodule in late stage of the disease, which requires surgical treatment alternatively. However, more importantly, the ultimate goals for treatment should be preventing fibrosis in an ealier stage of the disease and preventing atrophy after the surgical removal of the nodules.
Limitations of the current study are the small number of pediatric patients included because of the low prevalence of Coats’ disease, and only six patients with subfoveal nodules were included. Future large-scale studies with longer follow-up periods areneeded to confirm the efficacy of surgical excision of subfoveal nodules and to provide additional insight into histopathological features.
In conclusion, subfoveal fibrous nodules are pathological structures that result in poor vision due to long-term chronic inflammation within the retina. Surgery to remove subfoveal fibrous nodules can be a safe and efficacious treatment option in pediatric patients with Coats’ disease. Nodule development is associated with reactive myofibroblast proliferation and collagen production, as some nodules generate hyalinized tissue and ossified tissue. These histopathological findings suggested that early application of antifibrosis therapy could be potentially beneficial when the macula was involved.
Correction notice
NoneAcknowledgement
NoneAuthor Contributions
(Ⅰ) Conception and design: Xiaoshuang Jiang, Fang Lu(Ⅱ) Administrative support: Fang Lu
(Ⅲ) Provision of study materials or patients: Xiaoshuang Jiang, You Li, Yiliu Yang
(Ⅳ) Collection and assembly of data: Xuejiao Yu, Licong Liang
(Ⅴ) Data analysis and interpretation: Mengxi Shen, Guina Liu
(Ⅵ) Manuscript writing: All authors
(Ⅶ) Final approval of manuscript: All authors
