(A) Patient presents with a salmon-pink, poorly circumscribed subconjunctival mass with a maximum diameter of 1 cm on the medial wall of right orbit; (B) Axial and coronal computed tomography (CT) scan reveals multiple irregular-shaped soft tissue masses with unclear boundary in the medial and inferior wall of the orbit (red arrows), mostly contained inside the muscle cone, with marked homogeneous contrast enhancement (yellow arrow).
2.2 肉眼观察
送检眶内容标本大小4.5 cm × 4 cm × 4 cm,皮肤范围3.8 cm × 1.7 cm,眼球大小2.4 cm × 2.4 cm ×2.3 cm,于眶内容鼻侧见一不规则肿物,大小2.7 cm ×2.4 cm ×1.2 cm,切面灰红、灰褐色,实性,质地较细腻;另见灰黄、灰褐色碎组织,大小2.5 cm ×2.4 cm ×1 cm。
(A) The tumor is composed of hypercellular and tightly arrays of uniform spindle cells with collagen and vessels interspersed between the tumour cells (HE, ×40); (B) The tumor exhibits atypical spindle cell morphology with ovoid or rounded nuclei and scattered mitotic figures(arrow; HE, ×400); (C) Infiltration of the scleral surface is noted (HE, ×100); (D) Infiltration of the striated muscle is noted (HE, ×100).
荧光原位杂交(fluorescence in situ hybridization,FISH)检测:荧光显微镜下计数200个肿瘤细胞,>50%的肿瘤细胞内可见红绿分离信号,即有SS18基因易位(图4)。从而进一步证实我院报道的该例肿瘤具有特征性的t(x:18)(p11;q11)染色体易位,导致SS18(SYT)-SSX融合基因的产生,符合滑膜肉瘤的诊断。
图3 右眼鼻侧下方滑膜肉瘤患者免疫组织化学染色特征(IHC,×400)
Figure 3 Immunohistochemical stains of the patients with synovial sarcoma on the lower nasal right orbit (IHC, ×400)
(A) Vimentin expression in tumor cells; (B) Calpolnin expression in tumor cells; (C) CD99 expression in tumor cells; (D) Partial deletion of expression of INI-1 in tumor cells.
图4 FISH法检测到SS18分离信号(箭头所示)
Figure 4 SS18 separation signal (arrows) detected by FISH
2.5 病理诊断及随访
( 右眼眶)滑膜肉瘤(单相纤维型) 。随访4个月,未见肿瘤局部复发及远处转移。
3 讨论
S S是一种具有间叶和上皮双相分化的恶性肿瘤,在细胞遗传学上具有特异性的t(X;18)(p11;q11),并产生SS18(SYT)-SSX融合性基因[2]。SS好发于15~40岁的青少年,中位年龄为30岁,也可发生于10岁以下的儿童,男性多见[14]。SS病变部位广泛,大部分发生于四肢大关节附近,也可发生于身体内无滑膜的部位,如心包、肺、肾和头颈部等[2]。头颈部SS由Jernstrom[15]在1954年首次报道。既往研究[16]显示:头颈部SS尚常见,约占所有SS的3%~10%,年轻男性患者多见,临床上多表现为锥体旁口咽部和喉部的软组织肿块,也可出现声音嘶哑及吞咽困难。眼眶部位SS罕见,且均为个案报道,我们总结的共11例眼眶SS患者中年轻女性患者多见(男:女=2:9),与其他部位相比,该性别优势的具体原因不清楚,可能是由于病例数目较少,不一定具有统计学意义,也可能需要更多的大样本研究进行报道。本组病例术前病程范围较广,从1周到13年,11例中5例症状至少出现3年以上,可能由于早期肿瘤生长缓慢且位置较深难以发现,通常在肿瘤发生多年后出现临床症状而就诊。
1、Vezeridis MP, Moore R, Karakousis CP. Metastatic patterns in softtissue sarcomas[ J]. Arch Surg, 1983, 118(8): 915-918.
2、Deshmukh R, Mankin HJ, Singer S. Synovial sarcoma: the importance of size
and location for survival[J]. Clin Orthop Relat Res, 2004(419): 155-161.
3、Kadapa NP, Reddy LS, Swamy R, et al. Synovial sarcoma oropharynx - a
case report and review of literature[ J]. Indian J Surg Oncol, 2014, 5(1):
75-77.
4、Thomas C, Guillemin M. Typical primary synovial sarcoma of the
orbit[ J]. Doc Ophthalmol, 1966, 20: 484-499.
5、Ratnatunga N, Goodlad JR, Sankarakumaran N, et al. Primary biphasic
synovial sarcoma of the orbit[ J]. J Clin Pathol, 1992, 45(3): 265-267.
6、Votruba M, Hungerford J, Cornes PG, et al. Primary monophasic
synovial sarcoma of the conjunctiva[ J]. Br J Ophthalmol, 2002, 86(12):
1453-1454.
7、Shukla PN, Pathy S, Sen S, et al. Primary orbital calcified synovial
sarcoma: a case report[ J]. Orbit, 2003, 22(4): 299-303.
8、Hartstein ME, Silver FL, Ludwig OJ, et al. Primary synovial sarcoma[ J].
Ophthalmology, 2006, 113(11): 2093-2096.
9、Liu K, Duan X, Yang L, et al. Primary synovial sarcoma in the orbit[ J].
J AAPOS, 2012, 16(6): 582-584.
10、Stagner AM, Jakobiec FA, Fay A. Primary orbital synovial sarcoma: A
clinicopathologic review with a differential diagnosis and discussion of
molecular genetics[ J]. Surv Ophthalmol, 2017, 62(2): 227-236.
11、Xu P, Chen J. Primary synovial sarcoma of the orbit[ J]. Ophthalmol
Eye Dis, 2017, 9: 1179172117701732.
12、柯腾飞, 边莉, 杨亚英. 右眼眶滑膜肉瘤1例[ J]. 中国医学影像学
杂志, 2015, 23(3), 175-175,.
KE TF, BIAN L, YANG YY. Synovial sarcoma in the right
orbit: A case report[ J]. Chinese Journal of Medical Imaging, 2015,
23(3), 175-175.
13、Portelli F, Pieretti G, Santoro N, et al. Primary orbital synovial sarcoma
mimicking a periocular cyst[J]. Am J Dermatopathol, 2019, 41(9): 655-660.
14、Thway K, Fisher C. Synovial sarcoma: defining features and diagnostic
evolution[ J]. Ann Diagn Pathol, 2014, 18(6): 369-380.
15、Jernstrom P. Synovial sarcoma of the pharynx: report of a case[ J]. Am J
Clin Pathol, 1954, 24: 957-961.
16、Harb WJ, Luna MA, Patel SR, et al. Survival in patients with synovial
sarcoma of the head and neck: association with tumor location, size,
and extension[ J]. Head Neck, 2007, 29(8): 731-740.
17、Lagrange JL, Ramaioli A, Chateau MC, et al. Sarcoma after radiation
therapy: retrospective multiinstitutional study of 80 histologically
confirmed cases. Radiation Therapist and Pathologist Groups of the
Fédération Nationale des Centres de Lutte Contre le Cancer[ J].
Radiology, 2000, 216(1): 197-205.
18、郑红伟, 祁佩红, 薛鹏, 等. 滑膜肉瘤的CT、MRI影像表现与鉴
别诊断[ J]. 中国CT和MRI 杂志, 2013, 11(4): 100-103.
ZHENG HW, QI PH, XUE P, et al. CT, MRI imaging
findings and differential diagnosis of synovial sarcoma[ J]. Chinese
Journal of CT and MRI, 2013, 11(4): 100-103.
19、Fletcher CDM, Bridge JA, Hogendoorn P, et al. World Health
Organization classification of tumors of soft tissue and bone[M]. Lyon:
IARC Press, 2013: 468.
20、Su Z, Zhang J, Gao P, et al. Synovial sarcoma of the tongue: report of
a case and review of the literature[ J]. Ann R Coll Surg Engl, 2018,
100(5): e118-e122.
21、McBride MJ, Pulice JL, Beird HC, et al. The SS18-SSX fusion
oncoprotein hijacks BAF complex targeting and function to drive
synovial sarcoma[ J]. Cancer Cell, 2018, 33(6): 1128-1141.e7.
22、Carroll SJ, Nodit L. Spindle cell rhabdomyosarcoma: a brief diagnostic
review and differential diagnosis[ J]. Arch Pathol Lab Med, 2013,
137(8): 1155-1158.
23、Smith SC, Gooding WE, Elkins M, et al. Solitary fibrous tumors of the
head and neck: a multi-institutional clinicopathologic study[ J]. Am J
Surg Pathol, 2017, 41(12): 1642-1656.
24、Panigrahi S, Mishra SS, Mishra S, et al. Malignant peripheral nerve
sheath tumor presenting as orbito temporal lump: Case report and
review of literature[ J]. Asian J Neurosurg, 2016, 11(2): 170-171.
25、Scruggs BA, Ho ST, Valenzuela AA. Diagnostic challenges in primary orbital
fibrosarcoma: a case report[J]. Clin Ophthalmol, 2014, 8: 2319-2323.
26、Shields JA, Eagle RC, Marr BP, et al. Invasive spindle cell carcinoma
of the conjunctiva managed by full-thickness eye wall resection[ J].
Cornea, 2007, 26(8): 1014-1016.
27、Agarwal AP, Shet TM, Joshi R, et al. Monophasic synovial sarcoma of
tongue[ J]. Indian J Pathol Microbiol, 2009, 52(4): 568-570.
28、Fayda M, Aksu G, Yaman Agaoglu F, et al. The role of surgery and
radiotherapy in treatment of soft tissue sarcomas of the head and neck
region: review of 30 cases[J]. J Craniomaxillofac Surg, 2009, 37(1): 42-48.
29、Yang JC, Chang AE, Baker AR, et al. Randomized prospective study of
the benefit of adjuvant radiation therapy in the treatment of soft tissue
sarcomas of the extremity[ J]. J Clin Oncol, 1998, 16(1): 197-203.
30、Pappo AS, Fontanesi J, Luo X, et al. Synovial sarcoma in children and
adolescents: the St Jude Children’s Research Hospital experience[ J]. J
Clin Oncol, 1994, 12(11): 2360-2366.
